| Model |
ULTIMA CPX III |
ULTIMA CP PRO G2 |
| Extension bar |
400-6: 6-inch carbon extension
400-9: 9-inch carbon extension |
400-6: 6-inch carbon extension
400-9: 9-inch carbon extension |
400-6: 6-inch polygonal carbon extension
400-9: 9-inch polygonal carbon extension |
| weight |
400-6: 200g
400-9: 220g |
400-6: 206g
400-9: 225g |
400-6: 240g
400-9: 265g |
| Aperture Distance (APD) |
400-6: Max. 187mm/Min. 99mm
400-9: Max. 264mm/Min. 99mm |
400-6: Max. 187mm/Min. 99mm
400-9: Max. 264mm/Min. 99mm |
400-6: Max. 191mm/Min. 131mm
400-9: Max. 265mm/Min. 205mm |
| Elevation |
method |
Lockdown-less screw drive with jump mechanism |
Lockdown-less screw drive with jump mechanism |
Lockdown-less screw drive with jump mechanism |
| length |
100mm (approximately 4 inches) |
100mm (approximately 4 inches) |
100mm (approximately 4 inches) |
| Range of motion |
Approximately 73mm |
Approximately 73mm |
73mm |
| Movable step |
1 rotation = 1/32 inch (approximately 0.8 mm) |
1 rotation = 1/24 inch (approximately 1 mm) |
1 rotation = 1/32 inch (approximately 0.8 mm) |
| 1 click = 1/640 inch (approximately 0.04 mm) |
1 click = 1/480 inch (approximately 0.05 mm) |
1 click = 1/640 inch (approximately 0.04 mm) |
| Tilt adjustment |
Yes |
Yes |
Yes |
| Vintage |
Range of motion |
Approximately 10mm |
Approximately 10mm |
14mm (2nd axis offset +9mm/-7mm also available) |
| Movable step |
1 rotation = 1/32 inch (approximately 0.8 mm) |
1 rotation = 1/24 inch (approximately 1 mm) |
1 rotation = 1/32 inch (approximately 0.8 mm) |
| 1 click = 1/640 inch (approximately 0.04 mm) |
1 click = 1/480 inch (approximately 0.05 mm) |
1 click = 1/640 inch (approximately 0.04 mm) |
| Supported scopes |
Screw size No.10-32 |
Screw size No.10-32 |
Screw size No.10-32 |
| 2nd and 3rd axis adjustment |
Yes |
Yes |
Yes |
| extension |
length |
400-6: 157mm (approximately 6 inches)
400-9: 233mm (approximately 9 inches) |
400-6: 157mm (approximately 6 inches)
400-9: 233mm (approximately 9 inches) |
400-6: 157mm (approximately 6 inches)
400-9: 225mm (approximately 9 inches) |
| Adjustment Range |
400-6: 3.5 inches (approx. 89 mm)
400-9: 6.5 inches (approx. 165 mm) |
400-6: 3.5 inches (approx. 89 mm)
400-9: 6.5 inches (approx. 165 mm) |
400-6/400-9 common: 2.4 inches (60 mm) |
| Adjustment Steps |
0.5 inches (approximately 12.7 mm) |
0.5 inches (approximately 12.7 mm) |
0.47 inches (12 mm) |
| Main materials |
Elevation Department |
6000 series aluminum alloy |
6000 series aluminum alloy |
6000 series aluminum alloy |
| Box section |
6000 series aluminum alloy |
6000 series aluminum alloy |
6000 series aluminum alloy |
| extension |
carbon fiber |
carbon fiber |
carbon fiber |
| color |
Black, Blue, Red, Gunmetal Silver |
Black, Blue, Red, Gunmetal Silver |
Black, Blue, Red, Gunmetal Silver |
| Right/Low |
Yes |
Yes |
Yes |
| Release date |
2025 |
2022 |
2025 |
| accessories |
Sight soft case
No. 10-24 Mount fixing screws
Hex wrench 1.5mm/2mm/3mm
Sight plate x 1
Sight chart plate x 1
Plank tape
Offset bracket |
Sight soft case
No. 10-24 Mount fixing screws
Hex wrench 1.5mm/2mm/3mm
Sight plate x 1
Sight chart plate x 1
Plank tape
Offset bracket |
Sight soft case
No. 10-24 Mount fixing screws
Hex wrench 1.5mm/2mm/3mm
Sight plate x 1
Sight chart plate x 8
Blank tape |
| Instruction manual *See the website using the QR code |
Instruction manual and
warranty card |
Instruction manual *See the website using the QR code |
| Options (sold separately) |
Bridge Lock Extension Set |
- |
Offset Bracket
Bridge Lock Extension Set |
