SV BONY | SV28 HD | 20-60x 60 ARCHERY TARGET SCOPE | WITH STAND

Optical Specifications

• Magnification: 25× to 75×

• Objective Lens Diameter: 70mm

• Optical Coating: Fully Multi-Coated (FMC)

• Prism Type: Porro

• Prism Glass: BAK-4 (High-quality, bright image)

• Field of View: Wide at 25× – Narrow at 75×

• Eye Relief: 14mm–16mm

• Exit Pupil:

  • 25× → 2.8mm

  • 75× → 0.93mm

• Close Focus Distance: ~8 meters

• Body & Construction

  • Eyepiece Angle: 45° Angled Eyepiece (comfortable for target spotting)

  • Focus System: Smooth central focus wheel

  • Sunshade: Built-in retractable sunshade

  • Lens Protection: Included caps for objective & eyepiece

  • Water Resistance: IPX4 / splash-proof

  • Fog-Proof: Nitrogen-filled body

  • Material: High-strength composite body with non-slip armor

    Dimensions & Weight

    • Length: ~ 360mm

    • Weight: ~ 910g (scope only)

    • Tripod Compatibility: Standard 1/4-20 mounting hole

      Included Accessories

      • SV28 PLUS 25-75×70 Spotting Scope

      • Small Table Tripod (Short Stand)

      • Full-Size Tripod (Long Stand)

      • Lens Caps (Objective + Eyepiece)

      • Carrying Bag / Pouch

      • Cleaning Cloth

      • User Manual

        • NOTE:
        • SHIPPING CHARGES ARE EXTRA AS PER ACTUAL BASIS Prices are Negotiable for Regular customers at many Products. Be our regular Customer

• Model: SV28 (25-75×70)

• Intended Use: Archery target observation, birding, wildlife, long-range viewing, general outdoor observation.

• Prism Type / Glass: Porro Prism, H-K9L/BaK4 glass.

• Optics Coating: Fully Multi-Coated (FMC / MC) for improved light transmission & contrast.

Optical Performance

• Magnification (Zoom): 25× to 75×

• Objective Lens Diameter (Aperture): 70 mm

• Eyepiece / Exit Pupil / Eye Relief: Eye relief ~ 16 mm (low mag) to ~ 14 mm (high mag)

• Field of View (FOV): ~ 64–43 ft at 1000 yards (wide at 25×, narrower at 75×)

• Close Focus Distance: ~ 8 meters – allows viewing fairly nearby targets without needing long distance.

Mechanical & Build

• Eyepiece Design: 45° angled eyepiece — ergonomic for target viewing / archery range use.

• Sunshade: Retractable sunshade on objective lens to reduce glare and improve image under bright light.

• Focus Mechanism: Smooth focus wheel for precise focusing.

• Tripod Compatibility: Standard 1/4-20 thread for mounting on camera / spotting-scope tripods. Comes with a lightweight desktop tripod.

Durability & Weather Resistance

• Weatherproofing: Water-resistant (rated IPX4/IP65 depending on source) and fog-proof (nitrogen purged) — suitable for outdoor/rainy conditions.

• Body / Finish: Rugged housing, non-slip finish (for better grip in wet/dusty conditions) as cited by retailers.

Included Accessories / Package Contents (Standard / Typical Bundle)

• Spotting scope body

• SMALL & LONG BOW STAND

• Retractable sunshade (built-in)

• Protective lens caps (objective & eyepiece) & eyepiece cover

• Carrying / storage case

• Optional phone adapter (for digiscoping / photographing through the scope) — depending on version / bundle.

• Cleaning cloth and user manual.

• Suitable Activities

• Archery / target shooting — to spot arrow hits at long distance.

• Birdwatching, wildlife observation — good for distant subjects thanks to zoom and large objective lens.

• General long-distance observation — landscapes, outdoor scouting, scouting shooting results, etc.
