Beiter Rest for Recurve

   The Support has incorporated a revolutionary Guiding System for the Finger, which may change position, carried by a specific designed Spindle. Due to the Support being applied with a specific angle (max ca. 15°), the Arrow Position versus the Plunger and the Nocking Point may be determined and changed very quickly and more precise than with any other Rest on the market! A Scale offers the opportunity to re-position the Finger after tests or changes. At the moment three different Finger are available:

• 15-12-0,65 for shafts with small diameter, Ø 5,2mm +/-1mm
• 16-17-0,65 for shafts with medium diameter Ø 7,8mm +/-1mm
• 17-23-0,77 for shafts with large diameter Ø 9,3mm +/-1mm
• Two Finger (of the same make) are included in each Box, but extra Fingers are available as spare part.

3 Supports are available, differing in their thickness, to have the desired arrow position on bows with different cut-outs: #S1, #S2 (= #S1 + 1mm), #S3 (= S#1 + 2mm). A detailed information sheet is available PDF-Download. There you find all data you need to choose the right Beiter Rest for your Set-Up! Please note as folllows:

• On the Finger you will find some details to determine the used model: The number "15 (S #1)" respectively "17 (S #1)" tells, that this finger may be used up to arrow to handle distance 15mm respectively 17mm (Dist. "A").
• The circled number tells, which arrow diameter will best fit for the use: 12 from 10/64" to 14/64", 23 from 20/64" to 24/64".
• The number at the bottom of the finger (e.g. 0,65), informs about the thickness of the finger.

For the use of the Beiter Rest we suggest:

• Beiter Plunger: it has the same diameter (Ø 6,0mm) as the centering hole of the Beiter Rest. This allows an extremely precise positioning of the Beiter rest on the bow.
• Nockposition: Turn the nock so that the vanes are in a "Y-Position" to the string. (see picture ) In this position you may reach the best possible clearance and the arrow may pass the bow-window without interference!
